| Standard: ASTM, AISI, DIN, EN, GB, JIS, stainless steel pipe | Place of Origin: Guangdong, China (Mainland) | Brand Name: CHENGPU |
| Model Number: SUS 201 304 316 430 | Type: Welded | Steel Grade: 200,300,400 series |
| Application: decoration,construction,etc. | Welding Line Type: ERW | Thickness: 0.35-3mm |
| Outer Diameter: 8-219mm | Material: 200,300,400 series | Product name: stainless steel pipe/tube |
| Surface: 180G,320G,400G Satin/Hairline, 500G,600G Mirror finish | Surface finish: Polishing (180/220/240/320/400/600#), hairline etc. | Grade: 201,202,301,304,304L,316,316LPackaging & Delivery Packaging |
| Sample: Free | MOQ: 25 tons/40ft container | Polish: Bright or Mirror,Satin, Hairline, |
| Payment terms: T/T or L/C | Length: 6m or as customers' request | Certification: ISO |
Details: Each piece in polybag and several pieces per bundle,or according to customer's request.
Delivery Detail: 25-30 days after deposit.
| Grade | Tensile Strength | Yield Strength | Elogation | Hardness | Solution Annealing | |
| kgf/mm² （N/mm²） | kgf/mm² （N/mm²） | % | HRB(HV) | |||
| ASTM | TP304 | ≥53（515） | ≥21（205） | ≥35 | ≥90（200） | 1040-1150 Water Quenching |
| TP 304L | ≥50（485） | ≥17（170） | ≥35 | ≥90（200） | ||
| TP 316 | ≥53（515） | ≥21（205） | ≥35 | ≥90（200） | ||
| TP 316L | ≥50（485） | ≥17（170） | ≥35 | ≥90（200） | ||
| JIS | SUS 304 | ≥53（520） | ≥21（205） | ≥35 | ≥90（200） | 1040-1150 Water Quenching |
| SUS 304L | ≥49（480） | ≥18（175） | ≥35 | ≥90（200） | ||
| SUS 316 | ≥53（520） | ≥21（205） | ≥35 | ≥90（200） | ||
| SUS 316L | ≥49（480） | ≥18（175） | ≥35 | ≥90（200） | ||
| BG | 06Cr19Ni10 | ≥53（520） | ≥21（205） | ≥35 | ≥90（200） | 1040-1150 Water Quenching |
| 022Cr19Ni10 | ≥49（480） | ≥18（175） | ≥35 | ≥90（200） | ||
| 06Cr17Ni12Mo2 | ≥53（520） | ≥21（205） | ≥35 | ≥90（200） | ||
| 022Cr17Ni12Mo2 | ≥59（480） | ≥18（175） | ≥35 | ≥90（200） | ||
| EN | X5CrNi18-10/1.4301 | （500-700） | ≥21（205） | ≥35 | ≥90（200） | 1000-1100 Water Quenching |
| X2CrNi18-9/1.4307 | （470-670） | ≥18（175） | ≥35 | ≥90（200） | ||
| X5CrNiMo17-12-2/1.4401 | （510-710） | ≥21（205） | ≥35 | ≥90（200） | 1020-1100 Water Quenching | |
| X2CrNiMo17-12-2/1.4404 | （490-690） | ≥19（195） | ≥35 | ≥90（200） | ||
| Standard | Chemical Composition(%) | |||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | N | ||
| ASTM | 304 | ≤0.08 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 8.0-11.0 | 18.0-20.0 | - | ≤0.11 |
| 304L | ≤0.03 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 8.0-13.0 | 18.0-20.0 | - | ≤0.11 | |
| 316 | ≤0.08 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | ≤0.11 | |
| 316L | ≤0.03 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | ≤0.11 | |
| 430 | ≤0.12 | ≤1.00 | ≤0.01 | ≤0.040 | ≤0.03 | ≤0.75 | 16.0-18.1 | - | - | |
| JIS | SUS 304 | ≤0.08 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 8.0-11.0 | 18.0-20.0 | - | - |
| SUS 304L | ≤0.03 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 8.0-13.0 | 18.0-20.0 | - | - | |
| SUS 316 | ≤0.08 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | - | |
| SUS 316L | ≤0.03 | ≤1.00 | ≤0.02 | ≤0.045 | ≤0.03 | 12.0-16.0 | 16.0-18.0 | 2.0-3.0 | - | |
| SUS 430 | ≤0.12 | ≤0.75 | ≤0.01 | ≤0.040 | ≤0.03 | - | 16.0-18.0 | - | - | |
| BG | 06Cr19Ni10 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.0-11.0 | 18.0-20.0 | - | - |
| 022Cr19Ni10 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.30-12.0 | 18.0-20.0 | - | - | |
| 06Cr17Ni12Mo2 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | - | |
| 022Cr17Ni12Mo2 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | - | |
| 10Cr17 | ≤0.12 | ≤1.00 | ≤1.25 | ≤0.060 | ≤0.03 | ≤0.6 | 16.0-18.0 | - | - | |
| EN | X5CrNi18-10/1.4301 | ≤0.07 | ≤1.00 | ≤1.00 | ≤0.045 | ≤0.15 | 8.0-10.5 | 17.0-19.5 | - | ≤0.11 |
| X2CrNi18-9/1.4307 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.15 | 8.0-10.0 | 17.5-19.5 | - | ≤0.11 | |
| X5CrNiMo17-12-2/1.4401 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.15 | 10.0-13.0 | 16.5-18.5 | 2.0-3.0 | ≤0.11 | |
| X2CrNiMo17-12-2/1.4401 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.15 | 10.0-13.0 | 16.5-18.5 | 2.0-3.0 | ≤0.11 | |
| X6Cr17/1.4016 | ≤0.08 | ≤1.00 | ≤1.00 | ≤0.040 | ≤0.15 | - | 16.0-18.1 | - | ≤0.11 | |
