Stainless Steel Plate

Inquire Now Next Product

Products Details

Stainless steel plate can be made by hot rolling and cold rolling , including the thickness of 0.31-3.0 mm sheet and 2.5-16 mm slab.

Hot-rolled stainless steel plate	Cold-rolled stainless steel plate
Lower hardness	Hardness
Easy to process	Processing is relatively more difficult
Good plasticity and ductility	Not deformed
Lower intensity	High intensity
Poor surface quality ( Easily oxidized )	High surface finish
Slab	Sheet

Hot-rolled stainless steel, mechanical properties not as good as cold-rolled, but there are good toughness and ductility. Cold-rolled stainless steel plate due to the good hardening, toughness is low.
In order to ensure all kinds of stainless steel yield strength, tensile strength, elongation and hardness and other mechanical properties to meet the requirements, prior to delivery must be stainless steel annealing, solution treatment, aging heat treatment.

Product Spec

Finish	Thickness	Characteristics	Applications
No. 1	3.0mm~50.0mm	Finished by hot-rolling, annealing and pickling, characterized by white pickled surface	Chemical industry equipment, Industrial tanks
No. 2B	0.3mm~6.0mm	Finished by heat treatment, pickling after cold rolling, followed by skin pass line to be more brighter and smooth surface	General Application Medical Instruments,Tableware
No. BA (Bright Annealed)	0.5mm~2.0mm	Bright heat treatment after cold rolling	Kitchen utensil, kitchen ware,architectural purpose
No. 4	0.4mm~3.0mm	Polishing with No. 150 to No.180 mesh abrasivesThe most popular finishes	Milk & Food processing acilities, Hospital Equipment, Bath-tub
No. 8	0.5mm~2.0mm	A mirror-like reflective surface by polishing with finer abrasives over 800 mesh	Reflector, Mirror, Interior-Exterior decoration forbuilding
HL(Hair Line)	0.4mm~3.0mm	Finished by continuous linear polishing	Architectural purposes, escalators, kitchen ware vehicles

Please refer to the Standard Specification of Stainless Steel Sheet & Plate

THICKNESS (GAUGE)	Width*Length (mm)/ Thickness (mm)	1000*2000	916*2438	1219*2438	1219*3048	1219*6096	1524*3048	1524*6096
THICKNESS (GAUGE)	Width*Length (mm)/ Thickness (mm)	1000*2000	3'*8'	4'*8'	4'*10'	4'*20'	5'*10'	5'*20'
Length (INCH)		40"*80"	36"*96"	48"*96"	48"*120"	48"*240"	60"*120"	60"*240"
30	30			7.07
28	0.4			9.43
26	0.5	7.93	8.83	11.8	14.7
24	0.6	9.52	10.6	14.1	17.7
23	0.7	11.1	12.4	16.5	20.6
22	0.8	12.7	14.4	18.9	23.6		29.5
21	0.9	14.3	15.9	21.2	26.5		33.2
20	1.0	15.9	17.7	23.6	29.5		36.8
18	1.2	19	21.2	28.3	35.4		44.2
16	1.5	23.8	26.5	35.4	44.2		55.3
14	2.0	31.7	35.3	47.1	58.9		73.7
12	2.5			58.9	73.7		92.1
11	3.0			70.7	88.4		111
9	4.0			94.3	118		147
	5.0			118	147		184
	6.0			141	177	354	221	442
	7.0			165	206	412	258	516
	8.0			189	236	471	295	589
	9.0			212	265	530	332	663
	10.0			236	295	589	368	737
	11.0			259	364	648	405	810
	12.0			283	354	707	442	884
	13.0			306	383	766	479	958
	14.0			330	412	825	516	1031
	15.0			354	442	884	553	1105
	16.0			377	471	943	589	1179
	17.0			401	501	1002	626	1252
	18.0			424	530	1061	663	1326
	19.0			448	560	1120	770	1400
	20.0			471	589	1179	737	1473
	21.0			495	619	1237	774	1547
	22.0			518	648	1296	810	1621
	23.0			542	678	1355	847	1694
	24.0			566	707	1414	884	1768
	25.0			589	737	1473	821	1842
	28.0			660	825	165	1031	2063
	30.0			707	884	1768	1105	2210
	32.0			754	943	1886	1179	2358
	35.0			825	1031	2062	1289	2579
	38.0			896	1120	2239	1400	2800
	40.0			943	1179	2357	1473	2947
	42.0			990	1237	2457	1547	3094
	45.0			1061	1326	2652	1658	3315
	48.0			1131	1414	2829	1768	3536
	50.0			1178	1473	2946	1842	3684
